Form P-CAUA, P/N 271166 R2, Page 7
Replacement Belt-Driven Motors (See CODE 22, pages 3-4, for direct-drive
motor.)
See CODE 17, page 3-4, for contactors for 1 phase and 3 phase motors with
internal overloads. Motors in the tables on pages 6-8 that are highlighted in gray
do not have internal overload protection and must be used with the motor starter
and overload listed in the table. Starters and overloads listed for the motors not
highlighted are optional.
Replacement IEC Starters and Overloads (listed by motor)
When ordering a replacement IEC starter (contactor) or overload, check the
manufacturer’s number on both parts. If the number is different than that listed, both
components must be replaced. IEC starter (contactor) and overload are mounted on
rail, P/N 111387. Replacement holding coils (240V) are listed on page 8.
Replacement Belt-Driven Blower Motors and Starters
IEC
Adjustable
Overload
IEC Starter
(Contactor)
Code 45 - MOTOR Code 46 - Starter OVERLOAD Code 47 - STARTER
Type HP
Reznor
P/N
Mfr fla volt ph Service
Factor
Power
Factor EFF %
o.l.
min
o.l.
max
GE #
Reznor
P/N
Contactor
Reznor
P/N
OPEN 1/3 202091 AOS-BF2034 3.0 208 1 1.35 2.50 4.10 RTA1-K 151190 CL00A310T-L 151150
OPEN 1/3 202091 AOS-BF2034 3.0 240 1 1.35 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 1/3 115863 M3007 1.9 208 3 1.35 1.00 1.50 RTA1-G 151187 CL00A310T-L 151150
OPEN 1/3 115863 M3007 1.6 240 3 1.35 1.30 1.90 RTA1-H 151188 CL00A310T-S 151147
OPEN 1/3 115863 M3007 0.8 480 3 1.35 0.65 1.10 RTA1-F 151186 CL00A310T-S 151147
OPEN 0.5 102627 AOS-BF2054 5.1 208 1 1.15 4.00 6.30 RTA1-L 151191 CL00A310T-L 151150
OPEN 0.5 102627 AOS-BF2054 4.4 240 1 1.15 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
OPEN 0.5 159183 AOS-H880 2.5 208 3 1.25 1.80 2.70 RTA1-J 151189 CL00A310T-L 151150
OPEN 0.5 159183 AOS-H880 3.0 240 3 1.25 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 0.5 159183 AOS-H880 1.5 480 3 1.25 1.30 1.90 RTA1-H 151188 CL00A310T-S 151147
OPEN 0.75 93548 AOS-C426V1 5.5 208 1 1.25 5.50 8.50 RTA1-M 151192 CL00A310T-L 151150
OPEN 0.75 93548 AOS-C426V1 5.4 240 1 1.25 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
OPEN 0.75 36951 AOS-312P696 2.9 208 3 1.25 2.50 4.10 RTA1-K 151190 CL00A310T-L 151150
OPEN 0.75 36951 AOS-312P696 2.6 240 3 1.25 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 0.75 36951 AOS-312P696 1.3 480 3 1.25 1.00 1.50 RTA1-G 151187 CL00A310T-S 151147
OPEN 1.0 13685 AOS-C523 7.5 208 1 1.25 5.50 8.50 RTA1-M 151192 CL00A310T-L 151150
OPEN 1.0 13685 AOS-C523 6.5 240 1 1.25 5.50 8.50 RTA1-M 151192 CL00A310T-S 151147
OPEN 1.0 36580 AOS-H882 3.7 208 3 1.15 79 2.50 4.10 RTA1-K 151190 CL00A310T-L 151150
OPEN 1.0 36580 AOS-H882 3.2 240 3 1.15 79 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 1.0 36580 AOS-H882 1.6 480 3 1.15 79 1.30 1.90 RTA1-H 151188 CL00A310T-S 151147
OPEN 1.0 158175 AOS-E1006 1.1 575 3 1.15 82.50 1.00 1.50 RTA1-G 151187 CL00A310T-S 151147
OPEN 1.5 194202 AOS-C621 7.8 208 1 1.2 86.4 77.20 5.50 8.50 RTA1-M 151192 CL00A310T-L 151150
OPEN 1.5 194202 AOS-C621 7.5 240 1 1.2 86.4 77.20 5.50 8.50 RTA1-M 151192 CL00A310T-S 151147
OPEN 1.5 115859 AOS-H884 5.6 208 3 1.15 66.4 78.60 4.00 6.30 RTA1-L 151191 CL00A310T-L 151150
OPEN 1.5 115859 AOS-H884 5 240 3 1.15 66.4 78.60 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
OPEN 1.5 115859 AOS-H884 2.8 480 3 1.15 66.4 78.60 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 1.5 158162 AOS-E1007 1.6 575 3 1.15 85.3 84.00 1.30 1.90 RTA1-H 151188 CL00A310T-S 151147
OPEN 2.0 202581 AOS-RB1204A 12.3 208 1 1.15 8.00 12.00 RTA1-N 151193 CL01A310T-L 151155
OPEN 2.0 202581 AOS-RB1204A 12.3 240 1 1.15 8.00 12.00 RTA1-N 151193 CL01A310T-S 151152
OPEN 2.0 159327 AOS-H886 7 208 3 1.15 67 79% 5.50 8.50 RTA1-M 151192 CL00A310T-L 151150
OPEN 2.0 159327 AOS-H886 6.6 240 3 1.15 67 79% 5.50 8.50 RTA1-M 151192 CL00A310T-S 151147
OPEN 2.0 159327 AOS-H886 3.5 480 3 1.15 67 79% 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 2.0 158176 AOS-E1008 2.1 575 3 1.15 86 84.00 1.80 2.70 RTA1-J 151189 CL00A310T-S 151147
OPEN 3.0 111560 AOS-B735 13.7 208 1 1.15 10.00 16.00 RTA1-P 151194 CL02A310T-L 151159
OPEN 3.0 111560 AOS-B735 12.4 240 1 10.00 16.00 RTA1-P 151194 CL01A310T-S 151152
OPEN 3.0 159185 AOS-H845 9 208 3 1.15 8.00 12.00 RTA1-N 151193 CL00A310T-L 151150
OPEN 3.0 159185 AOS-H845 8.6 240 3 1.15 8.00 12.00 RTA1-N 151193 CL00A310T-S 151147
OPEN 3.0 159185 AOS-H845 4.3 480 3 1.15 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
OPEN 3.0 120019 AOS-H954 3.6 575 3 1.15 80.3 83.80 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
OPEN 5.0 111562 AOS-V211 28.3 208 1 1.15 25.00 32.00 RTA1-V 151199 CL04A310M-L 151169
OPEN 5.0 111562 AOS-V211 25.6 240 1 1.15 25.00 32.00 RTA1-V 151199 CL04A310M-S 151166
OPEN 5.0 113371 AOS-196033 13.4 208 3 1.15 87.2 85 10.00 16.00 RTA1-P 151194 CL01A310T-L 151155
OPEN 5.0 113371 AOS-196033 13.2 240 3 1.15 87.2 85 10.00 16.00 RTA1-P 151194 CL01A310T-S 151152
OPEN 5.0 113371 AOS-196033 6.6 480 3 1.15 87.2 85 5.50 8.50 RTA1-M 151192 CL01A310T-S 151152
OPEN 5.0 120020 AOS-H956 5.4 575 3 1.15 85.9 85.30 4.00 6.30 RTA1-L 151191 CL01A310T-S 151152
TEFC 1/3 159501 AOS-C151 2.3 208 1 1.90 2.70 RTA1-J 151189 CL00A310T-L 151150
TEFC 1/3 159501 AOS-C151 2.4 240 1 1.90 2.70 RTA1-J 151189 CL00A310T-S 151147
TEFC 1/3 105567 AOS-H261 1.2 208 3 1.00 1.00 1.50 RTA1-G 151187 CL00A310T-L 151150
TEFC 1/3 105567 AOS-H261 1.2 240 3 1.00 1.00 1.50 RTA1-G 151187 CL00A310T-S 151147
TEFC 1/3 105567 AOS-H261 0.6 480 3 1 0.40 0.65 RTA1-D 151184 CL00A310T-S 151147
