37
Q5RF SERIES SMALL PACK
UNIT
BLOWER
SETTING
External Static Pressure Drop - inches water column
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
X24K
Tap T1* 990 32 790 40 560 56 540 59
Tap T2** 1040 30 850 37 600 53 550 57 500 63
Tap T3 1080 29 920 34 800 39 720 44 680 46 620 51 570 55 520 61
Tap T4*** 1160 27 1100 29 1040 30 1000 32 960 33 900 35 850 37 820 39
Tap T5 1330 24 1300 24 1250 25 1200 26 1170 27 1130 28 1080 29 1030 31
X36K
Tap T1* 1020 31 840 38 600 53 500 63
Tap T2 1060 30 900 35 750 42 700 45 650 49 600 53 540 59 500 63
Tap T3** 1280 25 1240 25 1200 26 1180 27 1140 28 1100 29 1070 30 1010 31
Tap T4*** 1480 21 1450 22 1420 22 1390 23 1360 23 1320 24 1290 24 1240 25
Tap T5 1580 20 1550 20 1520 21 1480 21 1450 22 1420 22 1380 23 1350 23
X48
Tap T1* 1150 27 1090 29 1030 31 1000 32 950 33 900 35 850 37 800 39
Tap T2 1300 24 1270 25 1240 25 1200 26 1160 27 1120 28 1090 29 1050 30
Tap T3*** 1460 22 1430 22 1400 23 1370 23 1340 24 1300 24 1250 25 1200 26
Tap T4** 1520 21 1480 21 1450 22 1420 22 1390 23 1360 23 1330 24 1300 24
Tap T5 1740 18 1710 18 1680 19 1650 19 1620 20 1590 20 1540 21 1500 21
X60
Tap T1 1150 27 1100 29 1060 30 1030 31 980 32 950 33 900 35 870 36
Tap T2* 1250 25 1200 26 1170 27 1150 27 1130 28 1100 29 1060 30 1020 31
Tap T3*** 1560 20 1530 21 1500 21 1470 21 1450 22 1420 22 1390 23 1360 23
Tap T4** 1750 18 1700 19 1670 19 1630 19 1600 20 1580 20 1560 20 1530 21
Tap T5 1960 16 1930 16 1900 17 1860 17 1830 17 1800 18 1770 18 1740 18
NOTES:
Temperature rises shaded gray are for reference only. These conditions are not recommended.
* Denotes factory set low cooling & heating speed.
** Denotes factory set high cooling & heating speed.
*** Denotes factory set electric heating speed.
Table 37. Q5RF Series Blower Data - (Small Pack)
Q5RF-A SERIES SMALL PACK
UNIT
BLOWER
SETTING
External Static Pressure Drop - inches water column
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
X24KA
Tap T1* 535 59 485 65 445 71
Tap T2** 765 41 700 45 635 50 590 54 520 61
Tap T3*** 1180 27 1140 28 1100 29 1050 30 1000 32 650 49 900 35 840 38
Tap T4 1302 247 1260 25 1220 26 1172 27 1127 28 1090 29 1035 31 985 32
Tap T5 1450 22 1410 22 1377 23 1335 24 1293 24 1245 25 1205 26 1160 27
X36KA
Tap T1* 875 36 832 38 775 41 715 44 659 48 599 53 555 57
Tap T2** 1267 25 1229 26 1181 27 1135 28 1099 29 1045 30 994 32 790 40
Tap T3 1380 23 1340 24 1305 24 1260 25 1220 26 1180 27 1130 28 1075 29
Tap T4*** 1440 22 1400 23 1365 23 1320 24 1280 25 1235 26 1195 26 1145 28
Tap T5 1500 21 1460 22 1420 22 1380 23 1340 24 1290 24 1250 25 1210 26
X48KA
Tap T1* 1030 31 980 32 950 33 900 35 860 37 810 39 765 41 725 44
Tap T2 1275 25 1225 26 1195 26 1145 28 1105 29 1055 30 1015 31 975 32
Tap T3** 1525 21 1504 21 1460 22 1422 22 1380 23 1353 23 1305 24 1271 25
Tap T4*** 1710 18 1665 19 1638 19 1609 20 1575 20 1530 21 1493 21 1449 22
Tap T5 1790 18 1760 18 1727 18 1701 19 1665 19 1627 19 1587 20 1553 20
X60KA
Tap T1* 1140 28 1094 29 1051 30 1005 31 954 33 901 35 850 37 802 39
Tap T2 1375 23 1340 24 1310 24 1252 25 1235 26 1172 27 1160 27 1108 29
Tap T3** 1691 19 1659 19 1623 19 1586 20 1544 20 1504 21 1468 22 1424 22
Tap T4*** 1722 18 1692 19 1653 19 1615 20 1579 20 1539 21 1498 21 1454 22
Tap T5 1841 17 1804 18 1771 18 1731 18 1703 19 1659 19 1614 20 1578 20
Table 38. Q5RF-A Series Blower Data - (Small Pack)
