Q5RD SERIES SMALL PACK
UNIT
BLOWER
SETTING
External Static Pressure Drop - inches water column
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
CFM
HEAT
RISE
024K
Low T6 607 52 555 57 490 64 437 72 368 86 291 109 255 124
Med T5 † 899 35 854 37 802 39 743 43 670 47 601 53 533 59
High T4 1220 26 1178 27 1133 28 1091 29 1024 31 946 33 844 37 743 43
030K
Low 847 37 808 39 770 41 726 44 664 48 562 56 460 69
High † 1104 29 1114 28 1064 30 1010 31 935 34 846 37 710 44 536 59
036KA
Low † 1318 24 1284 25 1248 25 1207 26 1160 27 1110 28 1043 30 957 33
High 1551 20 1521 21 1477 21 1434 22 1388 23 1342 24 1263 25 1180 27
036K
Tap T1 1100 29 900 35 750 42 650 49 580 54 520 61 480 66 455 69
Tap T2** 1208 26 1080 29 1025 31 972 33 926 34 874 36 813 39 752 42
Tap T3* 1262 25 1199 26 1153 27 1110 28 1070 30 1027 31 965 33 906 35
Tap T4 1370 23 1333 24 1300 24 1260 25 1230 26 1180 27 1070 30 1010 31
Tap T5 1410 22 1340 24 1450 22 1320 24 1280 25 1240 25 1195 26 1150 27
042K
Tap T1 1480 21 1455 22 1415 22 1390 23 1355 23 1320 24 1290 24 1255 25
Tap T2* 1575 20 1545 20 1515 21 1475 21 1440 22 1420 22 1385 23 1345 23
Tap T3** 1635 19 1505 21 1575 20 1545 20 1515 21 1485 21 1455 22 1425 22
Tap T4 1775 18 1740 18 1715 18 1695 19 1665 19 1635 19 1610 20 1580 20
Tap T5 2065 15 2040 15 2020 16 1985 16 1960 16 1940 16 1905 17 1850 17
048KA
Low 1460 22 1440 22 1420 22 1390 23 1360 23 1325 24 1285 25 1235 26
Med † 1840 17 1815 17 1790 18 1760 18 1715 18 1660 19 1605 20 1535 21
High 2155 15 2115 15 2065 15 2020 16 1955 16 1895 17 1830 17 1740 18
048K
Tap T1 1480 21 1455 22 1415 22 1390 23 1355 23 1320 24 1290 24 1255 25
Tap T2** 1575 20 1545 20 1515 21 1475 21 1440 22 1420 22 1385 23 1345 23
Tap T3* 1635 19 1505 21 1575 20 1545 20 1515 21 1485 21 1455 22 1425 22
Tap T4 1775 18 1740 18 1715 18 1695 19 1665 19 1635 19 1610 20 1580 20
Tap T5 2065 15 2040 15 2020 16 1985 16 1960 16 1940 16 1905 17 1850 17
060K
Tap T1 1370 23 1340 24 1310 24 1280 25 1260 25 1230 26 1195 26 1160 27
Tap T2 1470 21 1440 22 1410 22 1380 23 1360 23 1320 24 1290 24 1250 25
Tap T3** 1550 20 1520 21 1480 21 1450 22 1430 22 1400 23 1380 23 1350 23
Tap T4* 1810 17 1770 18 1740 18 1720 18 1690 19 1660 19 1610 20 1575 20
Tap T5 1890 17 1870 17 1840 17 1820 17 1800 18 1770 18 1710 18 1670 19
NOTES:
Temperature rises shaded gray are for reference only. These conditions are not recommended.
* Denotes factory set cooling speed
** Denotes factory set electric heating speed
† Denotes Factory cooling and electric heating speed
Table 35. Q5RD Series Blower Data - (Small Pack)
