13
P7RD-A SERIES - 208/230V - SINGLE PHASE MODELS
MODEL
P7RD-
HEATER
(KW)
SINGLE CIRCUIT MULTIPLE SUPPLY CIRCUIT OPTION
MCA
REC, WIRE
GAGE
(90°C CU)
MOP
Circuit A (Compressor & Fan) Circuit B (Blower & Heater)
MCA
REC, WIRE GAGE
(90°C CU)
MOP MCA
REC, WIRE GAGE
(90°C CU)
MOP
024KA
0 16.8 12 25
5 29.8 10 30
8 44.3 8 45 - - - - - -
10 54.8 8 60 - - - - - -
030KA
0 17.4 4 25 - - - - - -
5 29.8 10 30 - - - - - -
8 44.3 8 45 - - - - - -
10 54.8 8 60 - - - - - -
15 79.8 4 80 54.8 8 60 25 10 30
036KA
0 23.7 10 35 - - - - - -
5 29.8 10 35
8 44.3 8 45
10 54.8 8 60
15 79.8 4 80 54.8 8 60 25 10 30
042KA
0 31.9 8 50 - - - - - -
5 31.9 8 50
8 46.3 8 50
10 56.8 6 60
15 81.8 4 90 56.8 6 60 25 10 30
20 106.8 3 110 56.8 6 60 50 8 60
048KA
0 37.3 8 60
5 37.3 8 60
8 46.3 8 60
10 56.8 6 60
15 81.8 4 90 56.8 6 60 25 10 30
20 106.8 3 110 56.8 6 60 50 8 60
060KA
0 45.3 8 70
5 45.3 8 70
8 48.3 8 70
10 58.8 6 70
15 83.8 4 90 58.8 6 70 25 10 30
20 108.8 3 110 58.8 6 70 50 8 60
Table 14. P7RD-A Electrical Data (2, 2.5, 3, 3.5, 4, & 5 Ton Units)
