The basic VCR/TV connection - antenna/cable to VCR to TV - is shown below. If you have a
Cable Box or a Direct Broadcast System, please see pages eight-nine. If you have a Stereo TV,
please see page 10. After you hook up the VCR, go to page 11 to turn on the VCR.
(TheVRB66l is illustrated here.TheVRB46l has single AUDIO IN/OUT jacks.)
6 Hookups without a Cable BoxIDirect Broadcast System
I
Disconnect the antenna or cable from your TV.
Antenna
Indoor/Outdoor
(300 ohm)
Cable
(75 ohm)
ANTENNA IN
Jack
(on back of TV)
2
Connect thè antenna or cable to thè ANT(enna) IN Jack of yourVCR.
Back ofVCR
Antenna
Indoor/Outdoor
(300 ohm)
' =
@L®1
©B©!
\ ANT
l
Cable
(75 ohm)
/>..T im CH 3 CH 4
OUT IN rм^
