MAX78630+PPM Evaluation Kit User Manual
4 Rev 0
1 Introduction
The MAX78630+PPM Evaluation Kit (EV kit) demonstrates the capability of the MAX78630+PPM for
monitoring a three-phase AC load using up to three voltages and three currents (sensors included). The EV kit
connects to a PC through a USB cable that provides both power and data communication to the board. A
Windows®-based graphical user interface (GUI) communicates with the device over a virtual for simplified
access to measurement data and controls.
1.1 Ordering Information
PART TYPE
MAX78630+PPMEVK1# EV Kit
#Denotes a RoHS-compliant device that may include lead that is
exempt under the RoHS requirements.
1.2 Package Contents
The MAX78630+PPM EV kit includes the following:
• MAX78630+PPM EV Board
• Three 50A Current Transformers (CR Magnetics CR-8449-2500-N)
• USB Cable Assembly USB A-B 28/24 1.8M (Tyco/Amp 1487588-3)
• CD with Documentation, GUI Application, and USB Drivers
• Calibration Coefficients Document (Hardcopy Only)
1.3 System Requirements
In addition to an AC source and load for measuring, the MAX78630+PPM EV kit requires use of a PC with the
following features:
• 1GHz processor and 1GB RAM
• Minimum 1024 x 768 video display resolution
• Available USB port
• Microsoft Windows 7 or Windows XP®
Windows and Windows XP are registered trademarks of Microsoft Corp.
