SPI/J16 Interface Configuration
Table 15: Jumper Settings for Connecting on J16
Jumper Position
J17 Removed
J18 Removed
J28 Removed
J29 Removed
J27 Removed
J38 Removed
J30 Inserted
J12 1-2
Table 16: J16 Connector Pin Assignment
Pin Number Pin Name Pin Description
1 +5V DC Connect to external source
2 SSB SPI Slave Select (SS)
3 MISO Slave Data Out
4 MOSI Slave Data Input
5 SCK Serial Clock
6 GND Ground
