MAX78630+PPM Evaluation Kit User Manual
Rev 0 13
2.4 Analog Input Jumper Descriptions
The following tables describe the various EV board jumpers that determine how analog signals are routed to
the inputs of the MAX78630+PPM.
Table 1: J15 Jumper Description
J15 Pins Description Default
1/2 MAX78630+PPM measures current IC (J41) -Default Installed
2/3 MAX78630+PPM measures shunt current IN (R11) 1/2
Table 2: J11 Jumper Description
J11 Pins Description Default
1/2 Measure two voltages (VB is reference) -Default Installed
2/3 Measure three voltages (N is reference) 2/3
Table 3: J13 Jumper Description
J13 Pins Description Default
1/2 Insert burden resistor on IA (installed: enable, open: disable) Installed
Table 4: J19 Jumper Description
J19 Pins Description Default
1/2 Insert burden resistor on IB (installed: enable, open: disable) Installed
Table 5: J42 Jumper Description
J42 Pins Description Default
1/2 Insert burden resistor on IC (installed: enable, open: disable) Installed
Table 6: J14 Jumper Description
J14 Pins Description Default
1/2 Enable 2nd RC filter on IA (installed: disable, open: enable) Installed
Table 7: J20 Jumper Description
J20 Pins Description Default
1/2 Enable 2nd RC filter on IB (installed: disable, open: enable) Installed
Table 8: J43 Jumper Description
J43 Pins Description Default
1/2 Enable 2nd RC filter on IC (installed: disable, open: enable) Installed
