ENGLISH
Aurora Series: Introduction
DVR User’s Manual
9
Remote Control
1 2 3
4 5 6
7 8 9
0 MENU
PTZ EXIT
STANDBY LOGIN/LOCK
OK
RECORD STOP EXTRA
AUDIO MUTE
2
3
5
7
11
12
14
17
18
20
22
9
4
6
1
10
13
15
19
21
23
16
8
1) Login/Lock: Press to login/lock the main menu. 13) -: Press to decrease the volume level.
2) Numeric keys (1~0): Press to display channel 1~16. 14) Record: Press to start manual recording.
3) Display mode: Press to switch to different display
mode.
15) Stop: Press to stop manual recording.
4) Menu: Press to enter the menu. 16) Extra: Reserved key.
5) PTZ: Press to configure PTZ settings. 17) Rewind: Press to rewind during video playback.
6) Exit: Press to exit the menu. 18) Play: Press to play recorded video.
7) OK: Press to enter the selected menu item and
confirm the setting.
19) Fast forward: Press to fast forward during video
playback.
8) Up: Press to move up in the OSD menu. 20) Slow play: Press to playback video at reduced
speed.
9) Left: Press to move left in the OSD menu. 21) Pause: Press to pause the video playback.
10) Right: Press to move right in the OSD menu. 22) Audio: In Playback mode, press to turn the audio
on.
11) Down: Press to move down in the OSD menu. 23) Mute: Press to mute audio.
12) +: Press to increase the volume level .
