¼ inch (6 mm) gap
7. The kit includes large- and
medium-sized foam pieces. In-
sert foam pieces inside the top
of the cap to keep the device
in place. Stack enough foam
so that when you slide the cap
into place with little pressure,
a ¼ inch (6 mm) gap remains
between the cap and the Field
PC. This gap closes when you
secure the cap in step 8.
8
6. Once you have inserted your card(s), hold it in place
while you tighten the adapter plate screws. Then
tighten the four small side
screws until the top of
each screw is flush
with the outside of
the gasket piece.
CAUTION: Before
removing an inserted card,
loosen the four small side
screws by 1 /
8
inch (3 mm).
Adapter
Plate
screws
