Juniper Systems ltra-Rugged Field PC Extended Caps User Manual
Page 14
8. Tighten the cap screws until they are firmly in
place. To properly seal the cap,
apply an extra ¼ to ½ turn after
the screws become hard to
turn.
14
9. Mount the sensor on the front of the extended
cap and secure it with a strap. Note: An optional
sensor mounting strap is available
for purchase.
The figure here
shows a GPS
antenna mounted
on the Universal
Cap and secured
with the sensor
mounting strap.
