Juniper Systems ltra-Rugged Field PC Extended Caps User Manual
Page 7
3. If you are inserting an SD or CF memory card, make it
easier to remove by first placing a card pull tab onto the
card.
4. There are two types of CF cards: Type 1 and Type 2.
A Type 1 card is thinner than a Type 2, and requires
the use of a spacer. To insert a Type 1 card, hold the
spacer (shown below) to the front of the card while you
insert the card into the rear slot of the adapter.
Type I CF card spacer
7
5. Once the card is placed in the adapter,
carefully align the card with the large
slot in the Field PC. Ensure that the
arrow on the adapter plate is pointing
towards the screen side of the Field PC.
