Universal and optical caps – Juniper Systems ltra-Rugged Field PC Extended Caps User Manual
Page 6
Universal and Optical Caps
1. Use a #1 Phillips screwdriver to loosen the captured top
screws on the Field PC. Remove the standard cap.
2. This section tells you how to insert your card(s) properly. For
memory cards, see step 3. For medium or large CF cards,
see step 4. For any other card types, insert your card(s) and
skip to step 5.
CAUTION: Before inserting a card, make sure the four
side screws on the seal adapter plate are backed out
1
/
8
inch as shown below.
6
Seal adapter plate
Side screws
