6 system menu, 7 video window function option – IC Realtime 2 Megapixel Full HD 20x Optical Network PTZ Camera IP66 300 ft IR (ICIP2001HDIR) User Manual
Page 9
5
Figure 1-7
Please refer to the following sheet for detailed information.
Parameter
Function
Brightness setup icon. It is to adjust
monitor video brightness.
Contrast setup icon. It is to adjust
monitor video contrast ness.
Saturation setup icon. It is to adjust
monitor video saturation.
Hue setup icon. It is to adjust
monitor video hue.
Video
setup
Reset
Restore brightness, contrastness
saturation and hue to system default
setup.
Note:
z All the operations here
apply to WEB end
only.
z Please go to Setup-
>Camera->Conditions
to adjust brightness,
contrast, hue and
saturation setup.
1.6 System Menu
System menu is shown as in Figure 1-8.
Please refer to chapter 1.3 Live, chapter 2 Setup, chapter 3 Alarm, chapter 5 Log out for detailed
information.
Figure 1-8
1.7 Video Window Function Option
The interface is shown as below. See Figure 1-9.
