Page 5
1
1 Network Connection
1.1 Preparation
This series speed dome product supports the Web access and management via PC.
Web includes several modules: monitor channel preview, PTZ control, system configuration, alarm and
etc.
Please follow the steps listed below for network connection.
z Make sure the speed dome has connected to the network properly.
z Speed dome IP address and PC IP address shall be in the same network segment. If there is router,
please set the corresponding gateway and subnet mask.
z Use order ping ***.***.***.***(* speed dome address) to check connection is OK or not.
1.2 Log in
Open IE and input speed dome address in the address bar.
For example, if your device IP is 192.168.1.108, then please input http:// 192.168.1.108 in IE address
bar. See Figure 1-1.
Figure 1-1
The login interface is shown as below. See Figure 1-2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Input your IP
address here
