IC Realtime 2 Megapixel Full HD 20x Optical Network PTZ Camera IP66 300 ft IR (ICIP2001HDIR) User Manual
Page 44
40
Parameter
Function
Record
channel
System auto activates motion detection channel to record once
video masking alarm occurs (working with motion detection
function). Please note you need to go to Storage-> Schedule to
set motion detect record period and go to Storage->Record
control to set current channel as auto record.
Record Delay
System can delay the record for specified time after video
masking alarm ended. The value ranges from 10s to 300s.
If you enabled this function, System can send out email to alert
you when alarm occurs.
PTZ
z
Here you can set PTZ movement when alarm occurs. Such as
go to preset x when there is an alarm.
z
The event type includes: preset, tour and pattern and etc.
Snapshot
It is snapshot activation function.
2.4.2 Alarm
2.4.2.1 Alarm activation
The alarm activation interface is shown as in Figure 2-31.
Figure 2-31
Please refer to the following sheet for detailed information.
Parameter
Function
Enable
You need to check the box to enable this function.
