IC Realtime 2 Megapixel Full HD 20x Optical Network PTZ Camera IP66 300 ft IR (ICIP2001HDIR) - Manual (Page 21)

17
Parameter Function
De-jitter Here you can set device de-jitter rate.
De-jitter enable Check the box here to enable de-jitter module.
2.2.2 Scene Setup
The scene setup is shown as in Figure 2-7.
Figure 2-7
Please refer to the following sheet for detailed information.
Parameter Function
Add scene Click it to add a scene.
Scene setup Click it to set current monitor video as the corresponding scene and get a number.
Preview scene Click it to preview the selected scene.
Zoom
Click to zoom in and click to zoom out.
PTZ
Click PTZ button to adjust scene position.
Speed It is to set PTZ movement speed. The value ranges from 1 to 8.
2.2.2.1
Single Scene
In Figure 2-6, select the single scene from the scene type list, you can see the single scene interface is
shown as in Figure 2-8.
Here you can select one item from the No. list to view one monitor scene.
