41
Parameter Function
Working
Period z This function becomes activated in the specified periods.
z There are six periods in one day. Please draw a circle to enable
corresponding period.
z Select date. If you do not select, current setup applies to today
only. You can select all week column to apply to the whole
week.
z Click OK button, system goes back to motion detection
interface; please click save button to exit.
Anti-dither
System only memorizes one event during the anti-dither period.
The value ranges from 0s to 100s.
Sensor type
There are two options: NO/NC. From NO to NC, system enables
alarm. From NC to NO, system disables alarm.
Relay out z Enable alarm activation function. You need to select alarm
output port so that system can activate corresponding alarm
device when alarm occurs.
z Please note the relay output number here is for reference
only. The alarm output number may vary due to different
series products.
Alarm Delay
System can delay the alarm output for specified time after alarm
ended. The value ranges from 10s to 300s.
Record
Channel System auto activates motion detection channel to record once
alarm occurs (working with motion detection function). Please
note you need to go to Storage-> Schedule to set current channel
as general record.
Record Delay System can delay the record for specified time after alarm ended.
The value ranges from 10s to 300s.
Send Email If you enabled this function, System can send out email to alert
you when alarm occurs and ends.
PTZ z Here you can set PTZ movement when alarm occurs. Such as
go to preset x when there is an alarm.
z The event type includes: preset, tour and pattern.
Snapshot You need to input capture channel number so that system can
backup motion detection snapshot file.
2.4.2.2 Relay output
The relay output interface is shown as in Figure 2-32.
