IC Realtime 2 Megapixel Full HD 20x Optical Network PTZ Camera IP66 300 ft IR (ICIP2001HDIR) - Manual (Page 43)

39
2.4.1.2 Video Masking
The video masking interface is shown as in Figure 2-30.
Figure 2-30
Please refer to the following sheet for detailed information.
Parameter Function
Enable You need to check the box to enable video masking function.
Sensitivity
There are six levels. The sixth level has the highest sensitivity.
Working
Period z Video masking function becomes activated in the specified
periods.
z There are six periods in one day. Please draw a circle to enable
corresponding period.
z Select date. If you do not select, current setup applies to today
only. You can select all week column to apply to the whole
week.
z Click OK button, system goes back to motion detection
interface; please click save button to exit.
Anti-dither
System only memorizes one event during the anti-dither period.
The value ranges from 0s to 100s.
Relay out Enable alarm activation function. You need to select alarm output
port so that system can activate corresponding alarm device when
video masking alarm occurs.
Please note the relay output number here is for reference
only. The alarm output number may vary due to different
series products.
Alarm Delay
System can delay the alarm output for specified time after video
masking alarm ended. The value ranges from 10s to 300s.
