45
z Yellow color stands for the motion detect record/snapshot.
z Red color stands for the alarm record/snapshot.
Figure 2-38
2.5.2 Destination
The destination interface is shown as in Figure 2-39.
It is to set the storage mode of the speed dome record file or snapshot pictures. There are two options:
local storage/FTP. You can only select one mode. System can save according to the event types. It is
corresponding to the three modes (general/motion/alarm) in the Schedule interface. Please check the
box to enable the save functions.
Figure 2-39
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type It includes: general, motion detect and alarm.
Local It is to save in the SD card.
FTP It is to save in the FTP server.
