44
Figure 2-37
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type z The abnormal events include: no disk, no space, disk error, net error,
offline, IP conflict.
z You need to draw a circle to enable this function.
Record System auto activates channel to record once an alarm occurs (For
offline type only. See Figure 2-37. ).
You need to check the box to enable this function.
Record
Delay System can delay the record for specified time after alarm ended. The
value ranges from 10s to 300s.
Relay Out The corresponding alarm output channel when alarm occurs. You need
to check the box to enable this function.
Relay out
Delay The alarm output can delay for the specified time after alarm stops. The
value ranges from 10s to 300s.
Send
email If you enable this function, system can send out email to alarm the
specified user.
2.5 Storage
2.5.1 Record schedule and snapshot schedule
In these two interfaces, you can add or remove the schedule record/snapshot setup. See Figure 2-38.
There are three record modes: general (auto), motion detect and alarm. There are six periods in one
day. Please make sure you have enabled the corresponding record mode in the Setup->Storage-
>Conditions.
You can view the current time period setup from the color bar.
z Green color stands for the general record/snapshot.
