1 Grounding
hole
2 Power
input
port
3 Power
button
4 Fan
5
The 1st to the 4th-channel audio input
6
DB25 port (the 5th to the 16th-channel audio input
port)
7
Loop video output
8 Video
input
9 Audio
output
10
Bidirectional talk input port
11
Bidirectional talk output port
12
Alarm input/alarm output
13
Video VGA output
14 HDMI
port
15 RS-232
port
16 eSATA
port
17 USB
port
18 Network
port
19 Video
CVBS
output
20
Video matrix output
21 Full-duplex
RS-485
port
22
Semi-duplex RS-485 port
When connect the Ethernet port, please use crossover cable to connect the PC and use
the straight cable to connect to the switcher or router.
2.3 Connection Sample
Please refer to the following figure for detailed information. See Figure 2-3.
