123

Parameter Function
Activation

preset x when there is an alarm.

Capture

You need to input capture channel number so that system can backup
motion detection snapshot file.

Matrix
Enable

Please note this function is valid in motion detect mode.
Check the box here to enable video matrix function. Right now system
supports one-channel tour function. System takes “first come and
first serve” principle to deal with the activated tour. System will process
the new tour when a new alarm occurs after previous alarm ended.
Otherwise it restores the previous output status before the alarm
activation.

Copy

It is a shortcut menu button. You can copy current channel setup to
one or more (all) channels.

Save

You can click save button after you complete setup for one channel, or
you can complete the whole setups and then click save button.

Refresh

Click this button to get device latest configuration information.

7.3.2.8 PTZ

PTZ interface is shown as in Figure 7-44.

Please note, before operation please make sure you have set speed dome address. And
DVR and speed dome connection is OK.

Figure 7-44

Please refer to the following sheet for detailed information.

Parameter Function

Channel

You can select monitor channel from the dropdown list. .
