7
It’s also important to know that your TX610 transmitter is capable of a system
reset. (See how this is done in the TX610 Manual.) If you decide to do a system
reset, the factory setup numbers to the Heli-Max AXE100 SS/SSL are listed here.
Below are the factory default parameters (Model Memory 8) for your AXE100
SS/SSL Helicopter.
AXE100 SS/SSL / TX610 1 AILE 2 ELEV 3 THRO 4 RUDD 5 GYRO 6 PITC
Type HELI
Swash Type 90 deg
Servo Reverse (NOR/REV) N N N N N N
Dual Rates (D/R) 80/100 80/100 80/100
Exponential (EXPO) -20 -20 0
Sub Trims (S-TRM) 0 0 0
Normal Throttle Curve (N-TH) 0 50 75 85 100
Normal Pitch Curve (N-PI) 45 50 55 62 68
UP-1 Throttle Curve HOV/FLAP.T DIAL
UP-1 PITCH Curve 30 40 52 60 70
Gyro Rate (G-S) 75 (Switch Down) 24 (Switch Up)
STICK CONTROLS
Throttle/Collective
Tail (rudder)
Left and right cyclic
Forward and back cyclic
