Heli-Max HMXE0828 - Manual (Page 12)

12
We have also included a basic setup for Spektrum ™ users as well.
AXE 100 SS/SSL / Spek DX6i AILE ELEV THRO RUDD GYRO PITC
Low 1 2 3 4 5 High 6
Type HELI
Reverse R R N R N N
Dual Rates (D/R) 100/80 100/80 100/100
Exponential (EXPO) Pos 20 Pos 20 0
Travel Adjustment 100% 100% 100% 100% 100% 100%
Norm Throttle 0 50 75 85 100
Norm Pitch 42 50 56 66 70
Stunt Throttle 100 95 90 95 100
Stunt Pitch 35 45 56 66 70
Throttle Hold ON 0%
Hold Pitch NULL
Gyro Mixing 70 switch up, 75 switch down
Swashplate Type 90deg
Timer 5min
Th is is a good setup for the Tactic 650
AXE100SS/SSL / Tactic 650 1 AILE 2 ELEV 3 THRO 4 RUDD 5 GYRO 6 PITC
Type HELI
Swash Type 1 Servo
Servo Rev N N R N N N
Servo Set Travel 100 100 H+125 100 100 100
Sub Trim 0 0 0 0 0 0
Dual Rate 100/80 100/80 100/100
Expo -20/-20 -20/-20 0/0
TH Cut Factory
TH Hold Factory
TH Curve Normal 0 NULL NULL NULL 100
TH Curve UP-1 100 NULL NULL NULL 100
PI Curve Normal -30 NULL 0% NULL +68
PI Curve UP-1 -68 NULL NULL NULL +68
Gyro +75 / +60
Throttle Mix NULL
Rev Mix NULL
Swash Ring 110
Program Mix NULL
Timer 5:00 Min
