11
5. Monitor the flashing LED. When it
stays on without flashing, your
transmitter is now linked to the
helicopter. Note: there is a second
LED in the center of the PCB. When
your transmitter is linked and the
helicopter held still this LED will
flicker, letting you know your
TAGS™ stabilization system is
working and ready.
TRANSMITTER SETUP GUIDELINES TO HELP YOU GET STARTED
FUTABA: You will fi nd that regardless of the Futaba system you choose, the
basic setup is the same. This includes the Futaba 6EX, 7C, T6J, TJ8 as well as
others. We have listed the setup of a Futaba T6J transmitter. It’s also worth
noting that even though the AXE100 SS/SSL uses 120 degree CCPM (Cyclic-
collective-pitch-mixing), with the Heli-Max TAGS system you must select the
90 degree swash arrangement. In a Futaba system this is called H-1 or 1-S
under swash type.
The setups listed are will get you going and might suit your fl ying style. If not
please feel free to make adjustments to suite your fl ying style.
AXE 100SS/SSL Futaba TJ6 1 AILE 2 ELEV 3 THRO 4 RUDD 5 GYRO 6 PITCH
Parameter (PARA) HELI
Reverse (REVR) N N R N N N
Dual Rates (D/R) 100/80 100/80 140/100
Exponential (EXPO) -10 -10 0
Normal Throttle (N-TH) 0 40 65 80 100
Normal Pitch (N-PI) 42 50 56 66 72
Idle Up Throttle (I-TH) 100 95 90 95 100
Idle Up Pitch (I-PI) 35 45 56 66 72
Throttle Hold (HOLD) ON 0%
Gyro Mixing (GYRO) ON SW A Pos 55 Pos 55
Swashplate Type (SWSH) H-1
Timer (TIMR) 5min
