4
Items in parentheses (GPMQ4243) are suggested part
numbers recognized by most distributors and hobby shops
and are listed for your ordering convenience. GPM is the
Great Planes brand, TOP is the Top Flite
® brand, HCA is the
Hobbico ® brand and COV is the Coverite ™ brand.
❏ 6+ Channel Radio with 7-10+ servos - each aileron
requires a 100 in oz single servo or twin 50+ in oz
servos PER aileron
Rudder requires a 100 in oz single servo or twin 50+
in oz servos
Twin elevator servos (80 in oz each minimum)
Standard Servo for throttle and onboard kill switch
1000+ mah Rx battery pack
AND
❏ Four 24” servo extensions - 2 aileron, 1 rudder, 1
elevator (HCAM1000 for Futaba ® )
❏ One Standard Y-Harness - 1 aileron (optional: 1
rudder) (HCAM2500 for Futaba)
❏ One Servo-Reverser and a Y-Harness or Reversing
Y-Harness for elevator (HCAM2500 for Futaba
Y Harness)
OR
❏ Computer radio and 24” and 36” servo extensions per
custom radio set up
❏ Engine and mounting hardware; See Engine Selection
❏ Muffler; See Exhaust System
❏ Propeller; Refer to your engine’s instructions for proper size
NOTE: We recommend staying with a 10 or lesser
pitch and the appropriate diameter for your engine
to optimize aerobatic performance and minimize
flutter risk on this model.
❏ Top Flite Super MonoKote covering (Approximately
three 25’ rolls); See Covering (page 3)
❏ Fuel-Proof paint; See Painting (page 44)
❏ Medium Gas Fuel Tubing (PRAQ1750, 3’)
❏ 24 oz. Fuel Tank (GPMQ4101 for gas or glow)
❏ Easy Fueler ™ Valve for Gas (GPMQ4161) or Glow
(GPMQ4101)
❏ 1/2” Latex Foam Rubber Padding (HCAQ1050)
❏ (2) 4-1/2” Wheels (DUBQ0846)
❏ 24 Giant Scale Pin Hinges (ROBQ2510)
❏ (4) 3/16” Wheel Collar (GPMQ4308)
❏ 5 (optional up to 8) Giant Scale Control Horns (DUBQ1985)
❏ (Optional) Onboard kill switch (GPMG2150) (mandatory
for gasoline engines)
❏ (2) 18” nylon pushrod for throttle (nylon required for
gasoline applications) (GPMQ3710)
❏ (2) 2-56 nylon clevises (GPMQ3800)
❏ (2) Screw Lock Pushrod Connectors (GPMQ3870)
❏ 6 (optional up to 9) 4-40 solder on clevises
(GPMQ3815, qty 12)
❏ 6 (optional up to 9) 4-40 thread on clevises with 12”
pushrod (GPMQ3785, qty 12)
❏ Giant scale tail wheel assembly and hardware (OHIQ2020)
❏ (2) 3/16” axles (long) (DUBQ1115)
❏ 5” Spinner (TRUQ2430 - aluminum, giant scale “Menz” cut)
❏ 2 Pilots (DGA 1/3 Scale Sportsman Pilot used in
prototype, DGAQ2000)
❏ (4) 1-ft sections of Velcro ™ or other non-adhesive-
backed hook-n-loop material
These are the building tools, glue, etc. that we recommend
and mention in the manual.
❏ (2) 4-oz. Thin CA (GPMR6004)
❏ (2) 4-oz. Medium CA+ (GPMR6010)
❏ CA Accelerator (GPMR6035)
❏ 6-Minute Pro ™ Epoxy (GPMR6045)
❏ 30-Minute Pro Epoxy (GPMR6047)
❏ Pacer Formula 560 ™ Canopy Glue (PAAR3300)
❏ HobbyLite
™ Balsa Filler (HCAR3401)
❏ Masking Tape
Building Supplies
Required Accessories
PREPARATIONS
Engine Selection
There are several engines that will work well in the Extra
330L, but for Unlimited-level competition or Tournament
style performance, we recommend a gasoline powered
twin cylinder 85cc such as the MacMinarelli 85 twin
(MMLG0085). For sport flying and competition through
the Advanced level, we recommend the MacMinarelli 70
twin (MMLG0070).
NOTE: Please see the FLYING section regarding flutter,
propeller selection and aerobatic performance.
Exhaust System Selection
You will need to choose an appropriate in-cowl muffler for
your engine. We chose the MacMinarelli exhaust system
designed specifically for the MacMinarelli 70 and 85
engines (MMLG9000).
Performance
You will need to decide if you want to perform the most
extreme of 3D aerobatics with this aircraft. If so, you will
want to consider four 80+ in. oz. servos for your ailerons
and two 80+ in. oz. servos for your rudder. Additionally,
you will need to double bevel the elevator leading edge.
Instructions to perform all of these modifications are
provided in shaded boxes.
DECISIONS YOU MUST MAKE
