GME G142CFD User Manual
Page 7
PA G E 8
I N S T R U C T I O N M A N UA L
G - C O M B O
NMEA 2000 Inputs from
compatible instruments
System date and time (PGN126992), Vessel Heading (PGN127250), Engine
parameters/Rapid Update (PGN127488), Engine parameters/Dynamic
(PGN127489), Trip parameters/Engine (PGN127497), Engine parameters/Static
(PGN127498), Fluid level (PGN127505), Water Speed (PGN128259), Water depth
(PGN128267), Position/Rapid Update (PGN129025), COG & SOG/Rapid Update
(PGN129026), GNSS Position Data (PGN129029), GNSS DOPs (PGN129539),
GNSS Sats in View (PGN129540), Wind Data (PGN130306), Environmental
Parameter-Water temp (PGN130310), Environmental Parameter (PGN130311).
NMEA 0183 Outputs, for
compatible instruments
APA, APB, BWR, GGA, GLL, GSA, GSV, RMB, RMC, VTG, XTE, DBT, DPT, MTW,
VHW, XDR
NMEA 2000 Outputs, for
compatible instruments
Water Speed (128259), Water depth (128267), XTE (129283), NAV. data (129284),
NAV. data (129285), COG & SOG (129026), GNSS position (129029), Water temp.
(130310).
G142CFD
GENERAL
Category
Detail
Size
164 mm(H) x 183 mm(W) x 74 mm(D)
Display
142 mm (5.6”) diagonal, TFT colour, 480 x 640 pixels.
Supply voltage
10 to 34 V DC
Supply current
13.8 V
800 mA min - no backlighting.
1000 mA max - full backlighting.
External beeper or light output
Switched to ground to sound alarm, 30 V DC, 200 mA maximum
Operating temperature
-10° to 50°C
ALARMS
User set: Arrival radius, anchor, XTE, danger, too shallow, too deep, fish, temperature, temperature rate, low battery, loss of
DGPS fix, dangerous AIS vessels.
GPS NAVIGATION
Chart card
C-MAP™ SD Card (NT-MAX, NT+ or NT)
User card
SD Card Maximum Memory size is 1 GB standard, 4 GB SDHC.
Waypoints
Up to 10,000, with default or user defined alphanumeric names up to eight
characters.
Routes
100 Routes, with up to 100 points each
Tracks
By time or distance, 10 track of 15,000 points
Chart datums
216 Chart datums, One user-defined map shift.
Chart scale
0.2 to 500 nm for chart (chart dependent) down to 0.005 nm in plotter mode.
COMMUNICATIONS
NMEA
NMEA 0183 4800, 9600, 38400 baud, NMEA 2000
NMEA 0183 Inputs from
compatible instruments
DBK, DBS, DBT, DPT, GGA, GLL, GNS, GGA, GSV, HDG, HDT, MDA, MTA, MTW,
MWD, MWV, RMC, RPM, VHW, VTG, VWT, ZDA
