Changing wheel position and modifying for left-hand use
23
B
e
for
e
Using
Changing the wheel position
The wheel position can be offset by using
the accessory APA wheel position offset
adapter. (See the page 24 for the modification
method.)
Angle can be adjusted
4HE
The operating angle of the wheel can be adjusted.
The operating angle of the wheel can be changed from 34 deg to 32 deg by installing
THE
)F
(page 116).
Modifying for left-hand use
The wheel section left and right installa-
tion direction can be reversed.
(See the page 26 for the modification method.)
Removing the steering wheel unit
s
screwdriver.
1
Hold the wheel and remove the
screw.
Steering wheel mounting screw
Unit mounting screws
2
Pull off the wheel and wheel
adapter.
Since the wheel adapter is 34 deg
as standard, install the 32 deg
wheel adapter at final installation.
3
Remove the 3 steering wheel unit
mounting screws.
Wheel
Wheel adapter
