FT-15(D) Technical Manual, Rev. 1.02 August 2010 Page 16 of 52
Second weighing cycle with printing first weighing label (parameter 045=1):
Steps Vehicle Position Description
There is no vehicle
on the weighbridge.
(Unloaded Scale) If the indication is not 0 kg, press the
key before loading the scale in the
instrument ready status.
[ 0 kg ]
Vehicle is parked on
the scale and the
engine is stopped. Load the scale.
[ 28680 kg ]
Press the key to start the
second weighing cycle.
[Second ]
Message will be displayed for 1 second.
[ Cod XX ] Enter temporarily the first weighing code.
[ First ]
[
9760 kg ]
The first weight in the memory will be
displayed. Press the key to go to
the next step
[ V. Id ]
[
584 ]
Enter the the vehicle ID numerically if this
entry is defined for the second weighing.
(refer to parameter [042]).
Press key.
[ Id1 ]
[
78 ]
Press the key to select from the ID
memory or press the key for a
numeric entry, if this entry is defined for
second weighing (refer to parameter [043]).
Press the key.
[ Id2 ]
[
22 ]
Press the key to select from the ID
memory or press the key for a
numeric entry, if this entry is defined for
second weighing (refer to parameter [044]).
Press the key.
[ Print ]
[
28680 kg ]
If the vehicle has finalized the weighing
process, press the key to save and
print the weighing result.
[ Sure XX ] If the displayed temporary first weighing
code is correct, press the key; if
not, press the key. The second
weighing ticket will be printed.
[ Unload ]
[
28680 kg ]
Message appears until the scale gets
unloaded.
Vehicle is on the
scale + the
displayed weight is
stable.
Vehicle leaves the
scale. Unload the scale. [ 0 kg ]
If the displayed weight is less than 20e or
the key is pressed, FT-15 returns to
the instrument ready status.
