FT-15(D) Technical Manual, Rev. 1.02 August 2010 Page 12 of 52
5.2 Keypad
The meaning of the front panel keys and the key functions are:
FT-15(D) Meaning
Power On/Off: This key is used for turning the instrument on or off. To switch off the key must be
pressed and hold at least for 2 seconds. There is no On/Off key on panel type housings.
Function: This key is used in combination with other keys to enter any function or to quit without saving.
Reset: Reset any weighing process
Info: This key is used to view the last printed ticket no. CN, the vehicle quantity in the temporary first
weighing memory [Temp ] as well as Date and Time information. To toggle between these infos you have
to press this key repeatedly and finally you will return to the weighing mode again.
Manual Zero: If the scale doesn’t show zero while there is no load on the scale, you can zero the scale
by pressing this key.
Key Lock Key:
You can activate or deactivate the key lock function by pressing the and
keys sequentially.
Transit: Pressing this key starts the transit weighing cycle.
Preset Vehicle Weighing: Pressing this key starts the weighing cycle with a preset vehicle weight value.
First weighing: Pressing this key starts the first vehicle weighing cycle.
Second weighing: Pressing this key starts the second vehicle weighing cycle.
Enter: This key is used to go to the next step within a weighing cycle. It is also used for confirming an
entered value and to get to the next parameter in setup mode.
ID: Used for numerical ID entry.
Numerical Keys: These keys are used for entering numerical values.
Memory: This key is used to enter data to the preset vehicle weight memory or the ID memory or to store
a vehicle weight to the memory.
High Resolution: By pressing this key the weight value will be shown with a higher resolution for a short
period.
Label No: After pressing this key, first [CN ] message appears on the display then you can see the CN
no. By pressing the key or after a while automatically it returns to weighing mode
Reprint: This key is used for reprinting the last weight ticket if the indicator is in the instrument ready
status.
Report Daily: This key is used for a daily report.
Report DD: This key is used for a report between two dates
Report CN: This key is used for a report between two ticket numbers.
Report Accu PV: This key is used for accumulator report of the vehicles in the preset vehicle
weight memory.
5.3 Key lock (for FT-15 only)
The instrument has the capability to lock the keys to avoid unauthorized person’s interference. You can activate
or deactivate this function by pressing the and keys sequentially. The LED with the key sign
(below the display) indicates the keys are locked.
