5
* These ports are available in Ingressus II.
LED light indicators
TCP/IP Ports
DIP
switch
RS485 connection
to PC/server
AUX output ports
(max 2 ports)*
Power input to
Ingressus
(Max 12V 3A)
Door lock system
output (door 1)
Door lock system
output (door 2) *
Power input for
door lock system
(Max 12V 3A)
AUX input ports
(Max 2 ports) *
RS485 reader
input ports
Status LED output
ports
Push release button
input ports (Door 1)
26-bit Wiegand
input ports
(Wiegand reader 1)
26-bit Wiegand
input ports
(Wiegand reader 2)
26-bit Wiegand
input ports
(Wiegand reader
3 & 4) *
Push release
button input
ports (Door 2) *
THE OvERvIEw OF HARDwARE
• Ingressus I & II
