FingerTec Ingressus IV - Manual (Page 17)

17
1
2
3
4
5
12V3A Power Supply
GND +12V
Note:
1. DO NOT install with door lock systems connected to
AC power.
2. Each door lock system should be installed with inde-
pendent power supply and backup battery.
3. Use 4-strand wire with standard RVV 4*0.75mm2 [2
for door lock (NO-COM / NC-COM), 2 for door sensor
(SEN-GND)].
4. Use 2-strand wires with standard RVV 2*0.5mm m2
for push release button.
5. DO NOT power up Ingressus or lock system during
wiring process.
6. For Ingressus IV, duplicate the connection of Ingres-
sus II.
SEN
GND
NO
COM
NC
LOCk 1
Door sensor
Override
keyswitch
(NC Type)
C
D
Emergency
break glass
(NC Type)
3
2
12VDC
Electromegnetic
door lock
--
+
SEN
GND
NO
COM
NC
LOCk 1
Door sensor
Override
keyswitch
(NO Type)
A
B
Emergency
break glass
(NO Type)
3
1
12VDC
Electromegnetic
door lock
--
+
IN
GND
Push release
button
12V3A Power Supply
GND +12V
LO
C
K
1
LO
C
K
2
SEN
GND
NO
COM
NC
SEN
GND
NO
COM
NC
RELAY
RELAY
CONNECTING TO DOOR LOCk SySTEM vIA DRy CONTACT
Set jumper inside Ingressus to
dry contact mode.
Type NC door lock system
Type NO door lock system
