Comtrol DM AIR - Manual (Page 44)

44 - DeviceMaster AIR User Guide: 2000365 Rev. C Updating Firmware
Updating the Wireless Firmware
default settings ( Factory Default Settings for the WLAN Port on Page 59).
You may want to save the wireless configuration settings but to upload the
settings, you will need to configure a host within the same range as the default
WLAN IP address of the DeviceMaster AIR (192.168.0.30). To save the
configuration settings, see
Saving the Wireless Configuration System Settings on
Page 23.
1. Make sure that you have downloaded and, if necessary, unzipped the wireless
firmware (
Latest Firmware on Page 39).
2. Connect the DeviceMaster AIR directly to a LAN network using an Ethernet
cable between the WLAN connector on the DeviceMaster AIR and the
Ethernet network.
3. Open the web browser and enter the DeviceMaster AIR IP address.
4. Select or type in user name in the User Name field.
5. Enter the password, if a password was configured during initial installation.
