Network Configuration for the Serial Portion

DeviceMaster AIR User Guide: 2000365 Rev. C - 29

Using PortVision Plus to Configure the Network Settings

You can use PortVision Plus to identify, configure, update, and manage the
DeviceMaster AIR from Windows 2000, Windows XP, and Windows Server 2003
systems. PortVision Plus automatically detects and identifies DeviceMaster AIR
products physically attached to the network for configuration, if they are in the
same network segment.

Note: You must have SocketServer 5.10 or NS-Link 5.04 or higher for all of the

property pages to appear. See

Locating Software and Documentation

Page 6 to locate the latest firmware or NS-Link driver.

Use the following procedure to change the network settings on the DeviceMaster
AIR.

If you have not done so, install PortVision Plus (

Installing, Updating, and

Removing PortVision Plus

on Page 28).

Start PortVision Plus from the Start button, Programs, Comtrol, PortVision Plus
or the PortVision Plus desktop shortcut. If this is the first time you have opened
PortVision Plus:

Select whether or not you want PortVision Plus to create shortcuts for the
COM port utilities; Test Terminal and Port Monitor.

Select the Scan button and Yes to locate DeviceMaster AIR units on the
network.

Highlight the DeviceMaster AIR for which you want to program network
information and open the Configure Device screen using one of these methods:

•

Double-click on the DeviceMaster AIR in the List View pane

•

Select the Config button

•

Right-click and select Configure Device from the popup menu

Note: See the PortVision Plus help system for information about using

PortVision Plus.

Optionally, rename the device in the Device Name field.
