1 6. SPECIFICATIONS
«■ai4ipa^ iic-mi4iKa *
Power source DC12V±10%
Power current consumption 250mA
Image element 1/2" interline-transfer CCD
(768H X 494V effective picture elements)
Scan area 6.54 mm x 4.89 mm
Scanning frequency 15.734 kHz (horizontal), 59.94 Hz (Vertical)
Sync, system Internal/External sync, (automatic change-over)
• C-SYNCA/S mode
• HD, VD mode
• Reset/Restart mode
• One-pulse trigger mode
Resolution 570 TV lines (Horizontal)
More than 400 TV lines (Vertical) at Frame accumulation mode
More than 350 TV lines (Vertical) at Field accumulation mode
Recommended illumination 36 lx(F1.6 3200K)
Minimum illumination 1.8 lx (50 IRE FI.6, y =0.45, built-in infrared-proof filter)
S/N ratio More than 56dB
( y = 1 ,
WEIGHT ON)
Output signal VSI.OVp-p, NTSC compatible
Output impedance 75Q, unbalanced
Infrared-proof filter Built-in (IK-M41F2) Dummy Glass (IK-M41R2)
Ambient temperature -10°Cto -h50°C(14F to 122F)
Ambient humidity 30% to 90%
Vibration resistance 68.6 m/sMiOto 200Hz)
Shock resistance
(camera head)
686 m/s2
Weight Camera 16g (0.56 oz) without lens
ecu 510g(18oz)
Dimensions Refer to 'PROFILE'.
Auxiliary
function
AES Auto (Automatic electronic shutter)/Manual/Fixed
(electronic shutter) (Factory preset at Manual)
Electronic
shutter
1/60,1/100,1/125,1/250,1/500,1/1000,1/2000,1/4000,1/10000 sec.
(Factory preset at 1/60 sec.)
(Every 1H between 1/60 to 1/30000 at one-pulse trigger mode)
Accumulation Field/Frame modes (Factory preset at Field)
Y correction 1/0.45 (Factory preset at 1)
Sensitivity Normal to -i-12dB (Adjustable) (Factory preset at normal)
Others Video index output. Video out field designation.
Video output (DC direct connection. Condenser coupling)
Options Refer to 'OPTIONS'.
* Design and specifications are subject to change without prior notice.
* Dimensions and weight are approximate ones.
NOTE: The camera head and the camera control unit (CCD) are to be used as a set with
matching numbers.
29
