Interlaced/non-interlaced operation may be carried out by changing the input phase con
ditions of HD and VD.
Interlaced operation
The input phases of VD and HD may be arranged to be ODD and EVEN alternately at
every 1 field so that the video output is interlaced. (Normal HD, VD Input)
Non-interlaced operation
The input phases of VD and HD may be arranged to be either ODD or EVEN only for all
the fields so that the video output is not interlaced. The 'non-interlaced' operation
refers to scan the same scanning line at every field. At non-interlaced operation, verti
cal resolutions may be decreased as shown in the table below.
Operation mode
Resolution
Frame accumulation interlaced mode
Fine
Field accumulation interlaced mode
Very Good
Frame accumulation non-interlaced mode
Good
Field accumulation non-interlaced mode
Good
