EXTERNAL SYNC. BY HD, VD
[
iwwiiiMil» gnd «wiicli setting for HP, VP
Input terminals
HD 6 pin (signal) and 5 pin (GND) of HD IN terminal (BNC connector) or DC IN/SYNC
terminal (12 pin connector)
VD 7 pin (signal) and 12 pin (GND) of VD IN terminal (BNC connector) or DC IN/SYNC
terminal (12 pin connector)
Switch setting
Signal
Input condition
S312
75Q terminated On/Off SW
S314
R.R. mode SW
HD, VD
3.0±1.5Vp-p, 7bQ unbalanced
ON
NORM
5.0±0.5Vp-p, TTL level
OFF
NORM
|S) Phos* and frequency cendMens of HD, VD
Phase condition
HD
VD
ODD FIELD
VD
EVEN FIELD
1H(63.5^s)
1/2H (31.8ns)
11 .Ons VD end edge is within this range.
15.8ns
15.9ns
\/r\ onri orlrje is
ange.
1
V L/ wl lU wUv
'
^ within this r
Frequency condition
HD:
15.734kHz ± 1% (63.56^s ± 1%)
VD:
More than 244H (1 H=63.56^is: 1 horizontal scanning period) at intervals of 0.5H.
Standard VD is 262.5H.
17
