APPENDIX A: REFERENCE
BACK PANEL
VCR
OUT
IN
IN FROM
ANT
A
r'* ^
AUDIO 1
1 1 O
w
OUT TO
TV
CH
A
X
©
m
3CH4 Switch Selects the channel to which you will tune the
TV to see the VCR picture if you connect the VCR using one of
the basic hookups.
AUDIO (R and L) and VIDEO IN Jacks Receives signals from
another component, like a VCR or camcorder, when it is
connected to these jacks. Use INPUT on the remote to select
LINE to record from these jacks.
AUDIO (R and L) and VIDEO OUT Jacks Sends signals from
VCR to another component, like a TV or VCR, when it is
connected to these jacks.
IN FROM ANT Jack Receives a signal from an antenna or
cable system when attached.
OUT TO TV Jack Passes signal to TV using the cable supplied.
