Measuring
Geometries: 0°/diffuse
Measuring
Aperture:
25.4 mm diameter
Measuring Field: 18.0 mm diameter
Color Sensitivity: Spectral
conformity to CIE
standard spectral
value function y,
under
Illuminant: CIE-C
(Cat.No. AT-4725)
CIE-A
(Cat.No. AT-4726)
Measuring Range:
4RANSMITTANCE
(AZE
#LARITY
Display
Resolution: 0.01 unit
(in range 0.00-9.99)
0.1 unit
(in range 10.0-99.9)
12. Technical Specifications Repeatability: ± 0.1 units*
Reproducibility: ± 0.4 units*
Measuring Time: 1-6 seconds
(depending on
mode)
Statistics
Memory:
7 x 999
measurements,
3 V lithium
battery backup
(CR 2450N FH)
Interface: serial RS-232,
interactive
Connectors:
RS-232: 9-pin
Sub-D
Foot switch: 15-pin Sub-D
Power Supply: 230 V/50 Hz,
115 V/60 Hz
Power Draw: max 200 VA
Fuses: Slo-blo 1.0 A;
250 V (230 V
power supply)
