42 BM series
Class Item and Parameter Description
0 Every measurement
1 2 seconds
2 5 seconds
3 10 seconds
4 30 seconds
5 1 minutes
6 2 minutes
7 5 minutes
int
Interval time
8 10 minutes
Interval time in the interval
memory mode when using prt
3,, data 1
off No output d-no
Data number output on
Output
Refer to " 12. Data Memory"
0 No output
1 Time only
2 Date only 5-td
Time/Date output
3 Time and date
Selects whether or not the time or
date is added to the weighting
data. Refer to " 10.7. Clock and
Calendar Function" for details.
off No output 5-id
ID number output
on Output
Selects whether or not the ID
number is output.
off No pause pU5e
Data output pause on
Pause (1.6 seconds)
Selects the data output interval.
off Not used at-f
Auto feed
on Used
Selects whether or not automatic
feed is performed.
0 No output
1 AD-8121 format
info
GLP output
2 General data format
Selects GLP output method.
Refer to "
11. ID Number And
GLP Report " for details.
off Not used ar-d
Zero after output on
Used
Adjusts zero automatically after
data is output
off Not output
dout
Data output
5-tp
Temperature output on
Output
Adds temperature to data output
0 600 bps
1 1200 bps
2 2400 bps
3 4800 bps
4 9600 bps
bp5
Baud rate
5 19200 bps
0 7 bits, even
1 7 bits, odd
btpr
Data bit, parity bit
2 8 bits, none
0 CR LF Crlf
Terminator
1 CR
CR: ASCII code 0Dh
LF: ASCII code 0Ah
0 A&D standard format
1 DP format
2 KF format
3 MT format
4 NU format
5if
Serial
interface
type
Data format
5 CSV format
Refer to " 10.5. Description of
Item "Data Format" ".
: Factory settings.
Caution The balance may not transmit the data completely at the specified refresh rate, depending
on the baud rate or data added to the weighing data such as time, date and ID number.
