6 E BL-1300-IM
 General specifications
*1 Specifications at 500 scans/second
· The laser classification for FDA(CDRH) is implemented based on IEC60825-1 in
accordance with the requirements of Laser Notice No. 50.
· To comply with UL/IEC60950-1, use the limited power source defined in
UL/IEC60950-1.
· The internal settings of the unit are written to the internal memory.
(Re-writable 100,000 times)
 Interface specifications
KEYENCE, at its sole option, will refund, repair or replace at no charge any
defective Products within 1 year from the date of shipment. Unless stated
otherwise herein, the Products should not be used internally in humans, for
human transportation, as safety devices or fail-safe systems. EXCEPT FOR
THE FOREGOING, ALL EXPRESS, IMPLIED AND STATUTORY
WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF
PROPRIETARY RIGHTS, ARE EXPRESSLY DISCLAIMED. KEYENCE
SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
CONSEQUENTIAL OR OTHER DAMAGES, EVEN IF DAMAGES RESULT
FROM THE USE OF THE PRODUCTS IN ACCORDANCE WITH ANY
SUGGESTIONS OR INFORMATION PROVIDED BY KEYENCE. In some
jurisdictions, some of the foregoing warranty disclaimers or damage limitations
may not apply.
E 1101-3
Specifications
Model BL-1300 BL-1301 BL-1300HA BL-1301HA
Type Standard type High-resolution
Scanning direction Front
Light source
Visible red semiconductor laser
(Wavelength: 660 nm)
Output 85 W
Pulse duration 112 s
Laser Class
Class 2 Laser Product
(IEC60825-1,FDA(CDRH) Part 1040.10)
Scan method Single Raster Single Raster
Focal distance 120 mm 90 mm
Reading distance
65 to 500 mm *1
(When narrow width is
1.0 mm)
45 to 270 mm *1
(When narrow width is
0.5 mm)
Reading bar width 0.125 mm or more 0.08 mm or more
Maximum reading label width
339 mm *1
(Distance 350 mm,
Narrow bar width 1.0
mm)
189 mm *1
(Distance 189 mm,
Narrow bar width 0.5
mm)
PCS 0.4 or more
Scan count 500 to 1300 scans/second
Supported codes
CODE39, ITF, Industrial2of5, Standard2of5,
COOP2of5, CODABAR, CODE128,
GS1-128, CODE93,
UPC/EAN, GS1 DataBar
Reading digit
74 digits
(148 digits for the CODE128 start character C)
En
vironment resistanc
e
Enclosure rating IP65
Ambient light Sunlight: 10000 lx, Incandescent lamp: 6000 lx
Ambient
temperature
0 to 45 C
Storage ambient
temperature
-20 to 60 C
Relative humidity 35 to 85%, No condensation
Operating
atmosphere
No dust or corrosive gas present
Vibration
10 to 55 Hz, amplitude 1.5 mm,
2 hours each in X, Y and Z directions
Rating
Power supply
voltage
5V DC 5%
Power consumption 400 mA max.
Weight Approx. 115 g
Model BL-1350HA BL-1351HA BL-1370 BL-1371
Type
High-resolution,
side-scanning type
Long distance type
Scanning direction Side Front
Light source
Visible red semiconductor laser
(Wavelength: 660 nm)
Output 85 W
Pulse duration 112 s
Laser Class
Class 2 Laser Product
(IEC60825-1,FDA(CDRH) Part 1040.10)
Scan method Single Raster Single Raster
Focal distance 65 mm 230 mm
Reading distance
40 to 250 mm *1
(When narrow width is
0.5 mm)
160 to 600 mm *1
(When narrow width is
1.0 mm)
Reading bar width 0.08 mm or more 015 mm or more
Maximum reading label
width
201 mm *1 (Distance
175 mm, Narrow bar
width 0.5 mm)
404 mm *1 (Distance
420 mm, Narrow bar
width 1.0 mm)
PCS 0.4 or more
Scan count 500 to 1300 scans/second
Supported codes
CODE39, ITF, Industrial2of5, Standard2of5,
COOP2of5, CODABAR, CODE128,
GS1-128, CODE93,
UPC/EAN, GS1 DataBar
Reading digit
74 digits
(148 digits for the CODE128 start character C)
En
vironment resistance
Enclosure rating IP65
Ambient light Sunlight: 10000 lx, Incandescent lamp: 6000 lx
Ambient
temperature
0 to 45 C
Storage ambient
temperature
-20 to 60 C
Relative humidity 35 to 85%, No condensation
Operating
atmosphere
No dust or corrosive gas present
Vibration
10 to 55 Hz, amplitude 1.5 mm,
2 hours each in X, Y and Z directions
Rating
Power supply
voltage
5V DC 5%
Power
consumption
400 mA max.
Weight Approx. 130 g Approx. 115 g
Input pin
2 (IN1, 2), no-voltage input
(contact, non-contact)
Output
pin
Output type 4 (OUT1 to 4) NPN open collector
Rating load 24 V DC, 30 mA
Leakage current at
OFF
0.1 mA or less
Residual voltage at
ON
0.5 V or less
Serial
interface
Transmission method EIA RS-232C compliant
Communication rate
600, 1200, 2400, 4800, 9600, 19200,
31250, 38400, 57600, 115200 bps
Synchronization Start-stop synchronization
Data length 7/8 bits
Stop bit length 1/2 bits
Parity check None/even/odd
