6 E SR-600-IM
Copyright (c) 2010 KEYENCE CORPORATION. All rights reserved.
11490E 1110-1 96M11490 Printed in Japan
* Use the Limited Power Source defined in UL/IEC60950-1 to comply with UL/
IEC60950-1.
KEYENCE products are strictly factory-inspected. However, in the event of a
failure, contact your nearest KEYENCE office with details of the failure.
1. Warranty period
The warranty period shall be for one year from the date that the product has
been delivered to the location specified by the purchaser.
2. Warranty scope
(1) If a failure attributable to KEYENCE occurs within the above mentioned
warranty period, we will repair the product, free of charge. However, the
following cases shall be excluded from the warranty scope.
• Any failure resulting from improper conditions, improper environments,
improper handling, or improper usage other than described in the
instruction manual, the user’s manual, or the specifications specifically
arranged between the purchaser and KEYENCE.
• Any failure resulting from factors other than a defect of our product,
such as the purchaser’s equipment or the design of the purchaser’s
software.
• Any failure resulting from modifications or repairs carried out by any
person other than KEYENCE staff.
• Any failure that can certainly be prevented when the expendable part(s)
is maintained or replaced correctly as described in the instruction
manual, the user’s manual, etc.
• Any failure caused by a factor that cannot be foreseen at a scientific/
technical level at the time when the product has been shipped from
KEYENCE.
• Any disaster such as fire, earthquake, and flood, or any other external
factor, such as abnormal voltage, for which we are not liable.
(2) The warranty scope is limited to the extent set forth in item (1), and
KEYENCE assumes no liability for any purchaser’s secondary damage
(damage of equipment, loss of opportunities, loss of profits, etc.) or any
other damage resulting from a failure of our product.
3. Product applicability
KEYENCE products are designed and manufactured as general-purpose
products for general industries.
Therefore, our products are not intended for the applications below and are
not applicable to them. If, however, the purchaser consults with us in advance
regarding the employment of our product, understands the specifications,
ratings, and performance of the product on their own responsibility, and takes
necessary safety measures, the product may be applied. In this case, the
warranty scope shall be the same as above.
• Facilities where the product may greatly affect human life or property,
such as nuclear power plants, aviation, railroads, ships, motor vehicles,
or medical equipment
• Public utilities such as electricity, gas, or water services
• Usage outdoors, under similar conditions or in similar environments
Specifications
Model SR-600 SR-610 SR-600HA
Type Short-range Mid-range
High
resolution
Laser pointer
Light source Visible semiconductor laser (660 nm)
Output 90 μW
Pulse width 200 μs
Laser class
Class 1
(IEC60825-1, FDA CDRH Part 1040.10)
Light
Light source High intensity red LED
LED class Class 1 (IEC60825-1)
Reading
Supported
code
Barcode
Code 39, ITF, Industrial 2of5,
COOP 2of5, NW-7 (Codabar),
Code 128, GS1-128
(EAN-128), GS1-DataBar
(RSS), Code 93, JAN/EAN/
UPC, Trioptic Code 39
-
2D Code
QR, MicroQR, DataMatrix, PDF417, MicroPDF,
MaxiCode, GS1-Composite
Focal distance 60 mm 100 mm 38 mm
Minimum
resolution
Barcode 0.127 mm 0.127 mm -
2D Code 0.127 mm 0.25 mm 0.082 mm
Reading time
(typical examples)
21 ms (focal distance, QR code 21 x 21)
Reading
distance
(typical
examples)
DataMatrix
35 to 95 mm
(Cell size
0.339 mm)
40 to 173 mm
(Cell size
0.508 mm)
19 to 51 mm
(Cell size
0.254 mm)
QR
31 to 97 mm
(Cell size
0.339 mm)
35 to 188 mm
(Cell size
0.508 mm)
17 to 54 mm
(Cell size
0.254 mm)
Barcode
29 to 106 mm
(Narrow bar
width
0.339 mm)
44 to 205 mm
(Narrow bar
width
0.508 mm)
-
Reading view range
(focal distance)
42.5 mm x
27.1 mm
70.6 mm x
45.0 mm
26.6 mm, x
17.0 mm
Input/output
Control input 2 non-voltage inputs (IN1, IN2)
Control output
4 NPN open collector outputs (OUT1 to OUT4)
30 mA max. (24 V or less)
Residual voltage 0.8 V or less, leakage current
0.1 mA or less
RS-232C
Communication
method
RS-232C standards
Transmission
speed
9600, 19200, 38400, 57600, 115200 bit/s
Synchronization
method
Asynchronous
Data bit
length
7/8 bits
Stop bit
length
1/2 bits
Parity check None/Even/Odd
USB Full-speed USB 2.0 interface
Environment
resistance
Enclosure rating IP65
Ambient temperature 0 to +45 ° C
Storage temperature -10 to +50 ° C
Relative humidity 35 to 95% RH (No condensation)
Ambient luminance
Sunlight: 10,000lx, incandescent lamp
6,000lx, fluorescent lamp: 2,000lx
Operating environment Location without dust or corrosive gas
Vibration
10 to 55 Hz: double amplitude 1.5 mm in the
X, Y and Z directions. 3 hours respectively.
Rating
Power supply voltage 5 VDC +5%, -10%
Current consumption 630 mA or less
Weight Approx. 160 g (including the cable)
Warranty
Model SR-600 SR-610 SR-600HA
Type Short-range Mid-range
High
resolution
