KEYENCE AP-C30(P) Series - Manual (Page 3)

3
After 4 sec
of no key
operation.
Reference value*
Press for 3 sec or more.
+
+
Increase the
setting.
Decrease the
setting.
Operating mode
Standard
Focus mode
AP-C30/C
35
AP-C31/
C31P/C33
/C33P
When
operating
mode is
• Two-point tuning
• Active tuning
Display color (7-segment)
ON: Red, OFF: Green
ON: Green, OFF: Red
Normally red
Normally green
Within set value: Green
Outside set value: Red
Detection range (AP-C30/C35)
Positive pressure range
Compound pressure range
Negative pressure range
Focus center pressure
■ Toggling the
display
■ Manual configuration
Settings are
manually
configured. The
display changes
for each mode.
* Toggling the
display of
settings (see the
diagram below).
* Manual
configuration
only during F-3/A-
2 mode operation.
Current value
Peak hold
Bottom hold
* The reference value is
the pressure value when
zero shift input is
received and is replaced
only when zero shift
input is selected.
■ Mode
configuration
Current value
Reference value
Hold value
Detection mode
General-purpose mode
Variable hysteresis mode
Window mode
Application mode 1
Application mode 2
Zero shift input
Analog output
N.O./N.C.
N.O.
N.O.
N.C.
N.C. N.O.
N.C.
N.C.
N.O.
Control
output 1
Control
output 2
2.5 msec
5
msec
100 msec
500 msec
Analog/zero shift
Chatter prevention
Sets response time.
• N.O. = normal open.
• N.C. = normal close.
Standard
Eco mode
Power-save
* See the Focus Mode section
of Part 9 for the center
pressures that can be
selected.
* F-1 and F-2 mode only
Values that fall between the P1
and P2 settings will be
displayed in green, while values
outside that range will be
displayed in red.
*
When
A-1/A-2 is
selected
The display color
is independent of
the control output.
The conditions of
ON/OFF in the
right table is the
case when N.O.
is set.
during
fixed mode
operation
( )
8. Sensor Configuration
■ Toggling the display of settings
●
General-purpose mode/F1
●
Variable hysteresis mode/F-2
●
Window mode/F-3
●
Application mode 1/A-1
●
Application mode 2/A-2
■ Two-point tuning (F-1/F-2)
The sensor is made to detect the pressures when the target object is
present and then absent for confirmation of target suction pick-up, and
the intermediate value is used.
Control output 1 configuration: When P1 (H1) is selected on the settings
display.
Control output 2 configuration: When P2 (H2) is selected on the settings
display.
Flashes
for 3 sec.
Setting
Target object
present
Target object
absent
■ Active tuning (A-1)
See Section 10.
Note: • Press and hold the MODE button ( ) for at least 3 seconds to return to the current
value/reference value/hold value display from each of the mode setting screens.
• Press the left side on the manual adjustment button ( ) while holding down the
mode button ( ) to return to the previous display.
• The current value will be displayed based on the ambient pressure conditions prevalent
at that time without regard to zero shift input when the P2 setting display is selected for
A-1 mode or when the Hi and Lo setting displays are selected for A-2 mode.
• The sensor must be configured manually when operating in the F-3/A-2 modes. The
SET button ( ) will not function.
