Communication Response Time
■ T5 (Response send time from DL-RS1A)
The time required to send a response varies depending on the communication speed, data bit
length, and number of bytes.
For information on the communication settings, refer to page 2.
The response time can be calculated using the following formula:
T5 = (number of bytes) x (data bit length + 4) / (communication speed)
●
Number of bytes for different commands
SR command : (number of bytes in the read data) + 12
M0 command : {(number of bytes in the read data) + 1} u number of connected sensor amplifiers + 4
MS command : {(number of bytes in the read data) + 3} u number of connected sensor amplifiers + 4
DRQ input
: {(number of bytes in the read data) + 3} u number of connected sensor amplifiers + 4
SW command : 11
AW command : 8
* For information on the number of bytes in the write data and the number of bytes in the read data,
refer to "Parameters of Commands and Responses" (page 10).
Sample calculation
■ T6 (Sensor amplifier settings change time)
For information on the calculation function, refer to the manual supplied with the sensor amplifiers.
● When calculation function of sensor amplifiers is OFF
T6 = 0 ms for SW and AW commands; the sensor amplifiers complete modifying their settings during
the T4 period.
* This table also applies to the sensor amplifiers that do not have the calculation function.
●
When calculation function of sensor amplifiers is ON
SW and AW commands both require the processing time shown below.
Number of bytes Data length Communication speed Response time
21 8 bit 9600 bps 26 ms
114 8 bit 9600 bps 143 ms
21 7 bit 38400 bps 6 ms
114 7 bit 38400 bps 33 ms
Number of connected sensor amplifiers Settings change time (T6)
1 7 ms
2 9 ms
3 13 ms
4 15 ms
5 19 ms
6 21 ms
7 25 ms
8 27 ms
9 31 ms
10 33 ms
Specifications
Performance Specifications
The following table shows the performance specifications for DL-RS1A.
* The number of connectable sensor amplifiers varies depending on the model to be connected.
• When configured with the GT-70A Series/FD-MA Series units: Up to 10 units (including the master unit)
(When multiple models are included, the maximum number of connectable units is limited to that of the model with
the least number of connectable units.)
Communication Specifications
The following table shows the communication specifications for DL-RS1A.
Item Specifications
Model DL-RS1A
Power supply voltage
20 to 30 VDC, including 10% ripple (P-P). Class2
(Supplied from the connected sensor amplifier)
Current consumption 25 mA max.
Number of connectable
sensor amplifiers
Varies depending on the model*
Indicators
2 communication status indicators (green), alarm indicator (red), power indicator
(green)
Environ-
mental
Ambient
temperature
-10 to +55°C (No freezing)
Relative
humidity
35 to 85% RH (No condensation)
Vibration 10 to 55 Hz, compound amplitude 1.5 mm, 2 hours for each of XYZ axes
Material Main unit housing: polycarbonate
Weight Approx. 53 g
Accessories
Instruction manual, 2 end units, expansion connector cover, switch protection
sticker
Item Specifications
Communication method Full duplex
Synchronization method Asynchronous
Transmission code ASCII
Communication speed
(Baud rate)
2400, 4800, 9600, 19200, 38400 bit/s
(Factory default: 9600 bit/s)
Data bit length 7 or 8 bits (Factory default: 8 bits)
Parity check None, even, odd (Factory default: none)
Stop bit length 1 bit
Data delimiter
Receive: automatically detect CR or CR + LF
Send: fixed to CR + LF
