Communication Response Time
Time Frames of Communication Response Time
This section describes the communication time frames (T2 to T6).
The maximum time required is shown for each time frame. However, depending on the
actual environment, it may require more time.
■ T2 (DL-RS1A data processing time)
For information on the calculation function, refer to the manual supplied with the sensor amplifiers.
● When calculation function of sensor amplifiers is OFF *
* This table also applies to the sensor amplifiers that do not have the calculation function.
●
When calculation function of sensor amplifiers is ON
■ T3 (Command send time from external device)
Refer to the manual supplied with the external device connected to DL-RS1A.
Reference
Number of connected
sensor amplifiers
Data processing time (T2)
GT-70A Series
1 7 ms
2 9 ms
3 13 ms
4 15 ms
5 19 ms
6 21 ms
7 25 ms
8 27 ms
9 31 ms
10 33 ms
Number of connected
sensor amplifiers
Data processing time (T2)
GT-70A Series
1 10.5 ms
2 13.5 ms
3 19.5 ms
4 22.5 ms
5 28.5 ms
6 31.5 ms
7 37.5 ms
8 40.5 ms
9 46.5 ms
10 49.5 ms
Communication Response Time
■ T4 (DL-RS1A command processing time)
The processing time varies according to the command sent from the external device.
● Read commands
● Write commands
Communication command
Number of connected
sensor amplifiers
Command processing time (T4)
GT-70A Series
SR
1 14 ms
2 15 ms
3 17 ms
4 18 ms
5 20 ms
6 21 ms
7 23 ms
8 24 ms
9 26 ms
10 27 ms
M0/MS/DRQ input 1 to 10 4 ms
Communication command
Number of connected
sensor amplifiers
Command processing time (T4)
GT-70A Series
SW
1 14 ms
2 15 ms
3 17 ms
4 18 ms
5 20 ms
6 21 ms
7 23 ms
8 24 ms
9 26 ms
10 27 ms
AW
1 57.5 ms
2 58.5 ms
3 60.5 ms
4 61.5 ms
5 63.5 ms
6 64.5 ms
7 66.5 ms
8 67.5 ms
9 69.5 ms
10 70.5 ms
