Hst 4 51 – Cub Cadet 7532 User Manual
Page 91
HST
4
51
3. After adjustment, make sure the HST pedal is operable to both forward and backward sides.
Fix
Release
Reverse
Forward
N
Trunnion arm
Forward stopper
Reverse stopper
HST pedal
Adjuster
Neutral arm
Grease
25 to 30 {0.98 to 1.18}
21.5
{0.84}
24
{0.945}
Spring
92 {3.62}
Bolt
Shaft
holder
Nut
Speed control rod
(418 {16.46})
Grease
Grease
mm {in}
GZ3W23-008
