Transmission

5.8.2

Assembly of Transmission Case Assembly (7530)

1. Adjust the endplay shown in the drawing to be

within 0.05 to 0.20mm {0.002 to 0.008in} with
liner "A".

(Unit: mm {in})

Item

Thickness

Parts No.

Liner "A"

0.2 {0.008}

0730 0006 202

0.6 {0.024}

0730 0006 206

22TL

25TR

20TL

30TL

24TL

29TR

14T

28T

33TL

16TR

19TR

34TR

33T

34T

19T

25T

35T

33TR

Sub gearing
Low-N-High

4-N-3

2-N-1

Main gearing

backward-N-forward

PTO drive shaft

4WD shaft

2WD-4WD

Grease

Liner "C"

Grease

Liner "A"

Liner "B"

Liner "D"

GZ3W24-045

33T

28T

19T

Liner "A"

GZ3W24-046
