7front axle 98 – Cub Cadet 7532 User Manual
Page 140
7
Front Axle
98
8. Remove the knuckle arm and final case.
9. Remove the kingpin case.
10. Remove the axle housing.
11. Remove the pinion assembly.
Reamer
bolt
Knuckle arm
Wheel case
Reamer bolt
Reamer bolt
GZ3W26-008
Kingpin case
Reamer bolt
GZ3W26-009
Deferential shaft gear
Reamer bolt
GZ3W26-010
Pinion assembly
GZ3W26-011
