1 Maintenance Standard
4
1.2 List of Standard Torque
Hexagon Head Bolt and Nut
Unit : (N•m {kgf•cm, lbf•ft})
Strength Classification
Designation
4T 7T 8T 9T 11T
M3
0.3 to 0.5 {3 to 5,
0.22 to 0.36}
- - - -
M4
0.8 to 1.0 {8 to 10,
0.58 to 0.72}
- - - -
M5
2.5 to 3.4 {25 to
35, 1.81 to 2.53} 5.4 to 6.4 {55 to
65, 3.98 to 4.7} 6.4 to 7.4 {65 to
75, 4.7 to 5.42} 6.4 to 7.4 {65 to
75, 4.7 to 5.42} 8.8 to 9.81 {90 to
100, 6.51 to 7.23}
M6
5.0 to 6.9 {50 to
70, 3.62 to 5.06} 9.8 to 11.8 {100 to
120, 7.23 to 8.7}
11.8 to 13.7 {120
to 140, 8.68 to
10.1} 11.8 to 13.7 {120
to 140, 8.68 to
10.1} 14.7 to 16.7 {150
to 170, 10.85 to
12.3}
M8
11.8 to 16.7 {120
to 170, 8.68 to
12.3} 24.5 to 29.4 {250
to 300, 18.1 to
21.7} 29.4 to 34.3 {300
to 350, 21.7 to
25.3} 29.4 to 34.3 {300
to 350, 21.7 to
25.3} 36.3 to 41.2 {370
to 420, 26.8 to
30.4}
M10
20.6 to 29.4 {210
to 300, 15.19 to
21.7} 39.2 to 44.1 {400
to 450, 28.9 to
32.5}
49 to 53.9 {500 to
550, 36.2 to 39.8} 49 to 53.9 {500 to
550, 36.2 to 39.8}
72.6 to 82.4 {740
to 840, 53.5 to
60.7}
M12
44.1 to 53.9 {450
to 550, 32.5 to
39.8} 83.4 to 93.2 {850
to 950, 61.5 to
68.7} 93.2 to 108 {950
to 1100, 68.7 to
79.6} 93.2 to 108 {950
to 1100, 68.7 to
79.6} 123 to 137 {1250
to 1400, 90.4 to
101.2}
M14
63.7 to 78.5 {650
to 800, 47 to 57.9}
118 to 132 {1200
to 1350, 86.8 to
97.6} 132 to 147 {1350
to 1500, 97.6 to
108.5} 147 to 167 {1500
to 1700, 108 to
123} 206 to 226 {2100
to 2300, 152 to
166}
M16
88.3 to 107.9 {900
to 1100, 65.1 to
79.6} 152 to 172 {1550
to 1750, 112 to
127} 177 to 196 {1800
to 2000, 130 to
145} 216 to 245 {2200
to 2500, 159 to
181} 314 to 343 {3200
to 3500, 231 to
253}
M18
118 to 137 {1200
to 1400, 86.8 to
101.2} 206 to 235 {2100
to 2400, 152 to
174} 245 to 275 {2500
to 2800, 181 to
202} 314 to 343 {3200
to 3500, 231 to
253} 441 to 471 {4500
to 4800, 325 to
347}
M20
147 to 167 {1500
to 1700, 108 to
123} 235 to 275 {2400
to 2800, 174 to
202} 314 to 353 {3200
to 3600, 231 to
260} 441 to 481 {4500
to 4900, 325 to
354} 618 to 657 {6300
to 6700, 456 to
485}
M22
177 to 206 {1800
to 2100, 130 to
152} 422 to 451 {4300
to 4600, 311 to
333} 539 to 579 {5500
to 5900, 398 to
427} 608 to 647 {6200
to 6600, 448 to
477} 843 to 883 {8600
to 9000, 622 to
651}
M24
235 to 265 {2400
to 2700, 174 to
195} 539 to 569 {5500
to 5800, 398 to
419} 706 to 745 {7200
to 7600, 521 to
550} 785 to 824 {8000
to 8400, 579 to
607} 1098 to 1138
{11200 to 11600,
810 to 839}
